Index>>VOIP Products>>Gateway devices
|
|
|
|
SIP Gateway
GN-08:
1 FXS,1
PSTN,2 LAN
|
| |
|
|
|
|
....... |
|
- SIP v1 (RFC2543), v2(RFC3261)
Support Route,Two
10/100Mbps MACs
Support T.38(Doing)
IP/TCP/UDP/RTP/RTCP
IP/ICMP/ARP/RARP/SNTP
TFTP
Client/DHCP Client/ PPPoE Client
Telnet/HTTP
Server
DNS Client
NAT/DHCP Server
Support G.723.1
5.3k/6.3k，G.729，G.711 A-Law、μ-Law audio codec algorithm
Dynamic voice detection Echo cancellation Comfort noise
generation
Tone generation and Local DTMF generation and
detection according with ITU-T
Settings by HTTP web
browser (IE6.0)
Advanced settings by Telnet
Voice
prompt
Upgrade by TFTP
|
Main chip: 32-bit RISC CPU with 125MHz clock
rate
Data storage:2MB SDRAM
Program memory: 1MB Flash
memory
Application Network environment: Two 10/100Mbps Fast
Ethernet MAC
Echo cancellation:G165 16ms
Store quick
dial number: 100
Record phone number of missed
call:80
Power loss:2.7W(max)
Power adapter: input AC
220V,output DC 9V 500mA |
|
|
Ambience temperature 0-40℃（32-104°F）
Relative
humidity 10-95%
Atmosphere pressure 86-106Kpa
Overall
size:113 x 80 x 28 mm (L x W x H)
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
| |
|
| |
